4Duino: 2.4-inch touchscreen, Arduino, and ESP8266 WiFi


Sep 21 2016

"At the heart of 4Duino-24 is an ATmega32U4 8-bit micro controller from Atmel. The same microcontroller is found on popular Arduino Leonardo. 4Duino-24 features a 2.4” colour TFT LCD display, with resistive touch. It is powered by the feature-rich 4D Systems Picaso Graphics Processor, which offers an array of display functionality and options for any Designer/ Maker. In addition, the 4Duino-24 features the popular ESP8266 Wi-Fi module which is pre-programmed with the AT command set firmware, enabling the 4Duino-24 to have many Wi-Fi capabilities right out of the box.

The 4Duino-24 also features an on-board microSD connector, and headers in the layout of an Arduino, including power pins (5V, 3.3V, GND and VIN), 20 digital IO pins, of which 7 can be used PWM outputs and 12 pins have Analog input capabilities."


More Details

Highlights

+ Available for 79 dollars http://www.4dsystems.com.au/product/4Duino-24

+ Video of graphics capabilities: https://www.youtube.com/watch?v=wWFuPpnkWSo

+ Created by Australian based 4D Systems

Additional Coverage

- http://hackerboards.com/4duino-combines-arduino-wifi-and-a-2-4-inch-touchscreen/

- http://tinkerman.cat/4duino-24-upside-down

- http://www.electronics-lab.com/4duino-2-4-tft-lcd-iot-display-module/
